Integrity ASV

Integrity™ ASV annular subsurface safety valves are validated to API Spec 14A (13th edition) V3-A, but their performance far exceeds the certification requirements for both barrier and hydraulic actuator integrity. They can be installed and retrieved in a single trip. Setting flexibility The integrated packer is set by pressuring up a dedicated hydraulic control line from surface, which eliminates tubing movement during the setting process. It can also be configured with a setting mandrel that enables conversion to traditional setting with tubing pressure. By placing a plug in the tubing below the Integrity ASV valve and plumbing the setting port to the setting mandrel, tubing pressure can be increased and communicated to the setting chamber for a more traditional packer setting sequence.
