ISV Series BF1E
Three piece bolted body design, forged construction floating type ball valve API 6D, API 608 design flanged or butt-weld end Sizes: 1/2″ – 2″ Pressure Range: ASME Class 600 & 1500 Port: Full Port (2″ reduced) Body Materials: A105, LF2, F316ss, F51ss Trim Materials: 316SS, 17-4ph, x19 or F51 Seat Materials: PEEK, Nylon, RPTFE or TFM Seal Materials: Viton+graphite, HNBR+graphite End Configurations: flanged or butt-weld ends Operator: Lever Locking Device: Standard Design Standard: API 608, API 6D, ASME B16.34 Pressure Test to API 598 or API 6D Conformance Standards: API 607 fire safe, ASME B16.5, B16.10, B16.34, NACE compliant
