Horizontal Fire & Smoke Curtain

Name: Horizontal Fire & Smoke Curtain
Brand: EFS Engineering Ltd.
Availability: InStock
Rating: 4.5 (1 reviews)

by EFS Engineering Ltd.

View EFS Engineering Ltd. on TEKEN44

Horizontal fire & smoke curtain is a unique solution for closing stairwells and atriums at a significantly lower cost compared to other rigid solutions, while reducing the costs and weight of the construction required for application around the horizontal opening. A fully motorized system consists of a control box, rollers, motors, fabric, bottom rod, side guides and electronic components. Each component is tested and approved individually to meet the stringent safety requirements 3 hours fire protection 4.5 hours smoke protection Two-hours heat radiation protection The curtains are installed in a unique, hidden and aesthetic method that assimilates them as an integral part of the building’s ceiling or wall so that it does not visually detract the overall design.

Applicable Standards

EN 1634-1
Fire resistance and smoke control tests for door and shutter assemblies, openable windows and elements of building hardware - Part 1: Fire resistance test for door and shutter assemblies and openable windows
EN 1634-3
Fire resistance and smoke control tests for door and shutter assemblies, openable windows and elements of building hardware - Part 3: Smoke control test for door and shutter assemblies
UL 10D
Standard for Fire Tests of Fire-Protective Curtain Assemblies
