Ball valves for hydrogen (H2) transport, storage & refueling systems

HFSV600

by MHA ZENTGRAF GmbH & Co. KG

View MHA ZENTGRAF GmbH & Co. KG on TEKEN44

Spindle valve HFSV600 for hydrogen applications up to 600 bar The spindle valve is the ideal solution for demanding industrial hydrogen applications up to 600 bar, where safety and reliability are paramount. The spindle mechanism allows for slow opening, minimizing pressure surges and ensuring smooth system operation. The adjustable double-layer stem sealing system with high-quality seals and optimized flange connections provide maximum safety and leak free operation even under extreme conditions (-40°C / +85°C). The HFSV600 is certified according to TPED ISO 10297, making it suitable for use in hydrogen MEGCs. It is also ATEX II C (H₂) certified for Ex-zone 1, 2G and designed for low-emission operation. H2 spindle valve HFSV600 features Sizes: DN11 Pressure rating: 650 bar Connections: threaded, flanged Bi-directional Tested according TPED directive(ISO 10297) Low emission design with secondary sealing barrier ATEX 2014/34/EU – compliant with Category IIC 2G, 3G AED-tested O-rings Materials according ISO11114
