View EMCO Controls on TEKEN44The EMCO wet gas meter is used to measure the flow rate in natural gasses with a certain level of liquid present. Based on the classical venturi tube according to ISO 5167-4 with single pressure tappings. A third tapping may be applied for liquid flow rate determination using the pressure loss ratio method. The system consists of a classical venturi tube in a metering section. The wet gas meter is designed to perform reliable measurements in applications such as well testing, hydrocarbon metering and monitoring of critical factors such as water breakthrough.
ANSI/ASME MFC-3M
Measurement of Fluid Flow in Pipes Using Orifice, Nozzle, and Venturi
ISO 5167-4
Measurement of fluid flow by means of pressure differential devices inserted in circular cross-section conduits running full Part 4: Venturi tubes
ISO/TR 15377
Measurement of fluid flow by means of pressure-differential devices — Guidelines for the specification of orifice plates, nozzles and Venturi tubes beyond the scope of ISO 5167 series
ISO/TR 11583
Measurement of wet gas flow by means of pressure differential devices inserted in circular cross-section conduits
