4.3" Touch-screen Terminal

For Pharmaceutical and Food Applications CFR 21-Part11 Compliance TD 430 In line with the peculiarities of the previous lines, this series also integrates a soft PLC (IEC 6-1131 standard) with the ability to manage external peripherals via RS485, Ethernet, USB or CAN interface or to create stand-alone applications using the ETD884 module where supervision, control logic and analog-digital I/O coexist in a single device, or even opt for combined solutions. The Runtime Suite provides an integrated soft PLC and programmable graphical environment. The soft PLC supports multi-task with execution up to 10 mS and includes Modbus RTU master/slave and Modbus TCP/IP master/slave and CAN Open Master communication drivers. Thanks to the integration of 5 different languages ​​according to the IEC 61131-3 standard (SFC - Sequential Function Chart, FBD - Function Block Diagram, LD - Ladder Diagram, ST - Structured Text, IL - Instruction List) and object-oriented programming for the graphics part, it is possible to create applications in a simple and intuitive way. This Suite development environment can also be used for programming the Panel-PC range, guaranteeing the portability of applications between different platforms for maximum flexibility and containment of programming times. Touch-screen Terminal Order Codes TD430-AD: 4.3" HMI with soft-plc + 1 RS485 serial + 1 CANopenETD884-AD: 2 An. Expansion 16bit/1msec (for load cells) + 8 In. + 8 Static + 2 Volt/mA outputs General features of the Touch-screen Terminal Container: 140x100 (front) x 38 Power supply: 12...24Vac/Vdc ±15% 50/60 Hz Consumption: 3.7W Display: LCD TFT touch screen 4.3" resolution 480x272 pixel 16 million colors, (lifetime typ. 50,000 hours @25°C) Environmental conditions: Temperature 0-45 °C, humidity 35..95 RH% Material: Front: aluminum with polycarbonate cover; Container: chromed steel Weight: Approx. 476 gr Protection: IP54 (Front), IP20 (Container and Terminal Blocks) Expansion on connector: ETD884-AD Expansion 2 load cell inputs with integrated cell power supply, 8 digital inputs, 2 24bit PNP/TTL encoder inputs, 8 digital outputs, 2 outputs analog V/mA, 4 NTC/PTC/V/mA inputs; Hardware Features and Communication Ports Processor: ARM V4i 200 MHz Memory: 256 MB Flash Communication serial: RS485 galvanically isolated Fieldbus: CAN galvanically isolated USB: 1 USB device for programming on the front + 1 USB 2.0 on the back Ethernet: 1 Ethernet 10/100 Base-T on RJ45 connector Memory card: SD/MMC reader Touch-screen Terminal Software Features Operating system: Windows CE 6.0 R3 Logic programming: LogicLab (Suite), languages ​​of your choice according to the IEC 61131-3 standard Graphical interface programming: PageLab (Suite) Communication protocols: Modbus RTU Master/Slave: Modbus TCT/IP master/sLAVE; CAN Open Master; Free port for modems or proprietary devices Clock: Real-Time clock with back-up battery
