COMPACT2 - DN 15 and DN 20
View G2 Misuratori S.r.l. on TEKEN44Compact electronic heatmeter, suitable for heat consumption measurements for central heating/cooling applications, and for hot water production sites Mid Directive 2014/32/EU, annex MI004 Accuracy class EN 1434 Class 2 Electromagnetic Class E1/Mechanical class M1 lectronic Unit Protection Class IP65 The meter is made of 03 main units: ultrasonic flow sensor, split electronic unit (85cm), pair of temperature sensors (1 inserted in the body, 1 loose) Bi-directional inductive detection (reverse flow) and air presence Powered by 3V lithium battery (replaceable), estimated duration of 10 years depending on environmental/working conditions or preset for external electrical power Possible installation on delivery pipes through software configuration Available version for high temperature for district heating (130°max)
