Ropstop III

by TECI

View TECI on TEKEN44

The ROPSTOP III accompanies the user when climbing up and down and in the event of a fall it blocks the rope and catches the user safely. ROPSTOP III also has a manual blocking function and can therefore be clamped onto the kernmantel rope. This function is particularly useful when used as a restraint system. The ROPSTOP III is available in various versions: Steel oval carabiner with band energy absorber attached to the ROPSTOP III with a screw link Steel oval carabiner with a 35 cm band connector attached to the ROPSTOP III Steel oval carabiner with a 60 cm band connector attached to the ROPSTOP III The band energy absorber reduces the load on the human body to less than 600 kg (6 kN) in the event of a fall. If the ROPSTOP III is used with the "band connector" version, a separate band energy absorber must be installed in the system. The ROPSTOP III is approved in combination with the following kernmantel ropes in accordance with EN 353 - 2: Dynaflex 12 mm Tutor XG 12 mm Patron 12 mm The kernmantle ropes are made from the factory with end connections (sewn loop, sewn-in carabiner, end knot). Specification: Fall arrest device made of galvanized and gold-chromated steel To open, several independent steps must be carried out: 1. Open the safety bracket 2. Press the flap 3. Pull out the bolt 4. The ROPSTOP III can then be opened"
