8NMEAto8-E – NMEA Matrix 8-Channel/Ethernet

Name: 8NMEAto8-E – NMEA Matrix 8-Channel/Ethernet
Brand: VEINLAND GmbH
Availability: InStock
Rating: 4.5 (1 reviews)

by VEINLAND GmbH

View VEINLAND GmbH on TEKEN44

8 NMEA 0183 interfaces (inputs and outputs) IEC 61162-1 (2 of them configurable as IEC 61162.2) NMEA 0183 ports can be switched as input and output; thus 16 ports Multiplexer and buffer / distributor / converter in one device Automatic bidirectional conversion between IEC 61162-1/-2 and the Lightwight Ethernet standard IEC 61162-450 Automatic grouping (multisentence messages) Tagblock configuration; data logging Configuration for proprietary multisentence messages possible Optional real time – time Server (NTP); time synchronization with GPS time Bidirectional conversion to UDP / TCP-IP / Multicast Cluster capability (several devices in a network); reduced cabling and installation costs In a cluster, all NMEA inputs are available at each device Fully configurable with included PC software Inputs and outputs are galvanically and optically isolated Intelligent data management prevents data errors Data filter dynamically adjustable for high performance

Applicable Standards

IEC 61162-1
Maritime navigation and radiocommunication equipment and systems - Digital interfaces - Part 1: Single talker and multiple listeners
IEC 61162-2
Maritime navigation and radiocommunication equipment and systems - Digital interfaces - Part 2: Single talker and multiple listeners, high-speed transmission
IEC 61162-450
Maritime navigation and radiocommunication equipment and systems - Digital interfaces - Part 450: Multiple talkers and multiple listeners - Ethernet interconnection
