ISV manufactures Industrial Gate, Globe & Check Valves to API design standards 594, 600, 603 & 623. Available size range is 2” through 36”. ASME pressure classes of 150 through 2500. Materials include WCB, LCC, C5, WC6, C12 & CF8M. Catalog download: ISV SB 900.3 web

Flexible Wedge/Solid Wedge/Split Wedge/Double disc, Outside Screw & Yoke, Bolted Bonnet Design, SW/SE/Flanged end/Welded end. Design Standards: API 600 (ISO-10434)/API-603/ASME B16.34 Size Range: ANSI Class 150 : 1/2" to 60" ANSI Class 300 : 1/2" to 48" ANSI Class 600 : 1/2" to 36" ANSI Cl

Design：API 600;API 603 Pressure-temperature rating：ASME B16.34 Face to face：ASME B16.10 Flange dimensions：ASME B16.5 Inspection & testing：API 598 Body material：A351-CF8;CF8M;WCB; CF3;CF3M;CN7M;

FLANGED /THRD,BUTT/SOCKET WELDING END Nominal Pressure

API 600 Gate Valve, ANSI Class Rated, Bolted Bonnet OS&Y Construction, with Position-indicating Rising Stem, and Non-rising Handwheel. End Connections: Flanged or Butt-welding Ends. Gate Design: Flexible, Solid, Double-disc, or Parallel Slide. Body Seat Design: Integral, Threaded, or Seal Welded in

Production Type: Pressure Seal Bonnet, Outside Screwed & Yoke Wedge Type:1 piece Flexible Wedge for 2” to 36” size valves in all classes 1 piece Solid wedge for 1-1/2”to 12” size valves in all classes of Light wall Thickness type Double Disc Parallel Seats for 2” to 60” size valves in all classes De

Trunnion Supported Fixed Ball Design, Available in Full or Reduced Bores. Features include Anti-blow-out Stem, Anti-static, Firesafe/Fire-tested, Lockable. Designs conform to API 608, API 6D, BS 5351, and ISO 17292 standards. Body styles include Two-piece and Three-piece. End connections are Flanged

Seat Supported Floating Ball Design, Available in Full or Reduced Bores. Features include Anti-blow-out Stem, Anti-static, Firesafe/Fire-tested, Lockable. Designs conform to API 608, API 6D, BS 5351, and ISO 17292 standards. Body styles include One-piece, Two-piece, and Three-piece. End connections

API 6D Swing Check Valve, ANSI Class Rated. Regular or Full Opening Type, Bolted Cover. End Connections: Flanged or Butt-welding Ends. Body Seat Design: Integral, Threaded, or Seal Welded in Place. Hinge Pin Designs: Internal Hanger or Through-body Pin. Options: Resilient Seating; Outside Lever with

Size: 2"(50mm) to 56"(1400mm) Class: 150# to 2500# Design: API 6D Ends: FF, RF, RTJ, SW, BW, NPT Bore: Reduced or Full Seat: Soft or Metal to Metal Materials: • Cast Carbon Steel : ASTM A105N, ASTM A 350 Gr. LF2; • Stainless Steel : ASTM A182 F316; • Duplex Stainless Steel : ASTM A182 F51; • Sup

Size: 2" (50mm) to 56" (1400mm) Class: 150# to 2500# Design: API 6D Ends: FF, RF, RTJ, SW, BW, NPT Bore: Reduced or Full Seat: Soft or Metal to Metal Materials: • Cast Carbon Steel : ASTM A105N, ASTM A 350 Gr. LF2; • Stainless Steel : ASTM A182 F316; • Duplex Stainless Steel : ASTM A182 F51; •

API 602 Gate Valve, ANSI Class Rated, Solid Wedge Gate, OS&Y Construction, with Position-indicating Rising Stem, and Non-rising Handwheel. End Connections: Flanged, Socket Weld, Threaded, or Butt-welding Ends. Bonnet Design: Bolted Bonnet, Welded Bonnet, or Pressure Seal Bonnet. Body Seat Design: Pr

API 602 Globe Valve, ANSI Class Rated, Plug Type Disk, OS&Y Construction. Integral Body Seat, with Position-indicating Rising Stem and Handwheel. End Connections: Flanged, Socket Weld, Threaded, or Butt-welding Ends. Bonnet Design: Bolted Bonnet, Welded Bonnet, or Pressure Seal Bonnet. Body Seat Des

JBF Series are quarter-turn ball valves engineered to provide a reliable performance for a wide range of applications, in industries such as Oil & Gas, Mining, Petrochemical, Chemical, Power Generation… Our vanguard design with many technically advanced features (optional fire-safe, longer stem, liv

JBFM Metal-Seat Ball Valve is designed especially for serve services with high temperature, abrasion or corrosion in the industrial processes. With JDV’s self-owned coating technology, a wide range of hard faces are available to satisfy all your using conditions.

To answer the growing demand of reliable and robust metal-seated threaded & welded ball valves, our experienced engineering teams designed the JBSM Series, meeting the requirements of the most challenging industries: Oil & Gas, Refineries, Petrochemical & Chemical Industries, Power Generation, Pulp

The JCT/JCTM trunnion-mounted 3/4-way ball valves are designed for the most complex flow control equations. Our unique 4-seat design with many alternatives of soft and metal seats allows the JCT/JCTM Series to withstand the toughest operating conditions in the fields of Oil & Gas, Refineries, Power

BS 1873 Globe Valve, ANSI Class Rated, Bolted Bonnet OS&Y Construction with Position-indicating Rising Stem, and Non-rising Handwheel. End Connections: Flanged or Butt-welding Ends. Disk Types: Plug, Parabolic, and Ball Type Disk. Body Patterns: Straight, Angle, and Y Patterns. Body Seat Designs: In

API 594 Type "B" Swing Check Valve, ANSI Class Rated, Bolted Cover. End Connections: Flanged or Butt-welding Ends. Body Seat Design: Integral, Threaded, or Seal Welded in Place. Hinge Pin Designs: Internal Hanger or Through-body Pin. Options: Resilient Seating; Outside Lever with Adjustable Weights,
